Price:
19,610.00 ৳
Asus PRIME B760M-K DDR5 mATX Motherboard
Key Features
Supported CPU: 14th 13th Gen & 12th Gen Processors
Supported Memory: 2 x DDR5, Max. 96GB 8000(OC)
Graphics Output: 1 x VGA port, 1 x HDMI
Features: 1 x Realtek 2.5Gb Ethernet
Specification
| Basic Information | |
| Supported CPU | Intel Socket LGA1700 For 13th Gen Intel Core & 12th Gen Intel Core, Pentium Gold And Celeron Processors Supports Intel Turbo Boost Technology 2.0 And Intel Turbo Boost Max Technology 3.0 |
| Chipset | Intel B760 Chipset |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC - Supports: Jack-Detection, Multi-Streaming, Front Panel Jack-Retasking - Supports Up To 24-Bit/192 KHz Playback Audio Features - Audio Shielding - Premium Audio Capacitors - Dedicated Audio PCB Layers |
| Form Factor | MATX Form Factor 9.6 Inch X 8.3 Inch (24.4cm X 21.1cm) |
| Expansion Slots | |
| PCI | Intel® 13th & 12th Gen Processors 1 X PCIe 4.0 X16 Slot Intel® B760 Chipset 2 X PCIe 4.0 X1 Slots |
| Memory | |
| Type | DDR5 |
| Slots | 2 X DIMM Slots |
| Supported Memory | 8000(OC)/7800(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC) /6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-Buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) |
| Maximum Memory | 96GB |
| Graphics | |
| Graphics | 1 X VGA Port 1 X HDMITM Port |
| Software | |
| Operating System | Windows® 11, Windows® 10 64-Bit |
| Connector & Ports | |
| USB (S) | Rear USB (Total 6 Ports) 4 X USB 3.2 Gen 1 (5G) Ports (4 X Type-A) 2 X USB 2.0 Ports (2 X Type-A） Front USB (Total 5 Ports) 1 X USB 3.2 Gen 1 (5G) Header Supports 2 Additional USB 3.2 Gen 1 Ports 2 X USB 2.0 Headers Support 3 Additional USB 2.0 Ports |
| Supported Storage | Total Supports 2 X M.2 Slots And 4 X SATA 6Gb/S Ports Intel 13th & 12th Gen Processors M.2_1 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X4 Mode) Intel B760 Chipset M.2_2 Slot (Key M), Type 2242/2260/2280 (Supports PCIe 4.0 X4 Mode) 4 X SATA 6Gb/S Ports |
| Internal I/O Ports | Fan And Cooling Related 1 X 4-Pin CPU Fan Header 2 X 4-Pin Chassis Fan Headers Power Related 1 X 24-Pin Main Power Connector 1 X 8-Pin +12V Power Connector Storage Related 2 X M.2 Slots (Key M) 4 X SATA 6Gb/S Ports USB 1 X USB 3.2 Gen 1 (5G) Header Supports 2 Additional USB 3.2 Gen 1 Ports 2 X USB 2.0 Headers Support 3 Additional USB 2.0 Ports Miscellaneous 2 X Addressable Gen 2 Headers 1 X Aura RGB Header 1 X Clear CMOS Header 1 X COM Port Header 1 X Front Panel Audio Header (AAFP) 1 X S/PDIF Out Header 1 X Speaker Header 1 X SPI TPM Header (14-1pin) 1 X 10-1 Pin System Panel Header |
| TPM (Trusted Platform Module ) | 1 X SPI TPM Header (14-1pin) |
| Others | |
| Special Features | ASUS 5X PROTECTION III - DIGI+ VRM - LANGuard - Overvoltage Protection - SafeSlot Core - Stainless-Steel Back I/O ASUS Q-Design - Q-DIMM - Q-LED Core - Q-Slot ASUS EZ DIY - ProCool ASUS Thermal Solution - VRM Heatsink Design Aura Sync - Aura RGB Header - Addressable Gen 2 Headers |
| Bundled Software | ASUS Exclusive Software Armoury Crate - Aura Sync - Fan Xpert 2+ - Power Saving - Two-Way AI Noise Cancellation AI Suite 3 - DIGI+ VRM - PC Cleaner ASUS CPU-Z Norton 360 Deluxe (60 Days Free Trial) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode |
| Warranty Information | |
| Warranty | 3 Years |
Asus PRIME B760M-K DDR5 mATX Motherboard
The Asus PRIME B760M-K DDR5 mATX Motherboard is a feature-rich and highly capable motherboard designed to support the latest Intel processors, providing a solid foundation for building a high-performance desktop system. It's engineered to accommodate 13th Gen Intel Core, 12th Gen Intel Core, Pentium Gold, and Celeron processors, offering excellent compatibility for various computing needs. The motherboard is built around the Intel B760 chipset and boasts a multitude of features and capabilities that make it a compelling choice for both enthusiasts and mainstream users. It comes with a 128 Mb Flash ROM UEFI AMI BIOS, ensuring smooth and user-friendly system setup and configuration. One notable highlight of the PRIME B760M-K is its support for DDR5 memory, with two DIMM slots that can accommodate a maximum of 96GB of RAM. This memory type offers impressive speeds, with overclocking support up to 8000 MHz, providing ample bandwidth for demanding tasks. The motherboard also caters to gamers and multimedia enthusiasts with a robust graphics configuration. It includes a VGA port and an HDMI port, offering versatile display options. The Realtek 7.1 Surround Sound High Definition Audio CODEC, complete with audio shielding, premium audio capacitors, and dedicated audio PCB layers, delivers exceptional audio quality for an immersive entertainment experience. In terms of connectivity, the PRIME B760M-K is well-equipped. It features various USB ports, both on the rear and front panels, along with multiple M.2 slots and SATA 6Gb/s ports for storage options. This ensures ample connectivity and storage expansion capabilities. ASUS has integrated several premium features into the motherboard, such as ASUS 5X PROTECTION III for enhanced durability and ASUS EZ DIY features for convenient installation and maintenance. Additionally, Aura Sync technology allows for customizable RGB lighting, while bundled software like Armoury Crate, AI Suite 3, and ASUS CPU-Z provides tools for system optimization and customization.
What is the price of Asus PRIME B760M-K DDR5 mATX Motherboard in Bangladesh?
The latest price of Asus PRIME B760M-K DDR5 mATX Motherboard in Bangladesh is 19,610৳. You can buy the Asus PRIME B760M-K DDR5 mATX Motherboard at best price from our website or visit any of our showrooms.
| Brands | Asus |
